JOKIMAN POCKET JC-300/500 [PRODUCT OUTLINE] JOKIMAN POCKET JC-300/500 is installed on the side panel of a floor-type fan coil with the steam nozzle inserted to the upper part of the coil for humidification. Maximum reliable PTC immersion heaters enable this compact model to be high-security and durable. Use of pure water for water supply assures a long period of maintenance-free operation. [FEATURES] - Since it is vapor humidifying, it gives bacteria-free, odorless and clean humidification - With quick evaporation, it gives highly efficient humidification without condensation - Steam humidification makes a comfortable sensible temperature even when adjust the room temperature down - No loss in static pressure - Long life with no wear and tear of the essential parts [APPLICATIONS] - Offices - Hotels - Hospitals - Nursing home and other types of protective care institutions - Public facilities - Art museums - Libraries - Natural history museums

JOKIMAN POCKET JP-300/500 [PRODUCT OUTLINE] This model is installed on the secondary side of the coil of a floor-type fan coil unit or a compact-sized air conditioner. The humidification chamber is made small and deters accumulation of scale or mineral matter dissolved in water. Use of pure water for water supply helps make long period of maintenance-free operation possible. [FEATURES] - Compact size and simple installation - A full-fledged humidification with steam - With quick evaporation, no vapor comes out visibly from the outlet port - Uses maximum reliable and safe PTC immersion heater [APPLICATIONS] - Floor-type fan coil unit - For use in a compact-sized air conditioning unit

MAGY UC-MGS Series [PRODUCT OUTLINE] MAGY has been designed with emphasis on (1)safety, (2)easy maintenance (3)high precision proportional control. Safety Besides a circuit breaker for electric leakage, a device to prevent waterless operation, and a resettable thermostat; MAGY has as its standard equipment a voltage tripper to trip the breaker so as to prevent the unit from continuing its steam generation to cause over-humidification even when the signal is off in a unlikely event the magnet switch’s contact should become welded. Easy maintenance It is possible to check the heater or remove scales without having to take out the humidification tank. It takes only 20-30 seconds to dismantle the bottom plate. It is operated with normal city water, especially use of RO water makes maintenance reduce. High precision proportional control Differently from electrode steam humidifier, proportional control can be used by the stable current value. [FEATURES] - Fitted with a voltage tripper, ensuring ultimate safety - Water leak sensor, water supply shutoff valve (optional) - Removable bottom plate to facilitate the removal of scales - Possibility for high precision proportional control - Equipped to prevent accumulation of minerals with systematic drainage - Possibility to take signal externally - Built-in time counter - Possibility of direct in-room humidification with use of a fan unit - Normal tap water, softened water, pure water are available - Ultra pure water can be used - Self-cleaning super alloy incoloy [APPLICATIONS] - Clean rooms - Office buildings - Hospitals - Factories - Bedrock baths
